Poor Man's VPN Connection

No VPN into the customer's network? One ssh -D command turns a Linux box you can reach into a SOCKS proxy, and your browser does the rest.

Tony Mattke · 2010.04.20 · 2 min read

Have you ever needed to access a site that had an IP restriction, or one inside your remote network? Recently I need to access a customers remote monitoring site, but its restricted to a small subnet of IPs. They had no VPN setup for me, so I had to come up with something new…

The answer was creating an ssh connection to their network firewall, which happened to be a custom Linux box I had access to. The setup is actually quite simple, and requires no changes to the remote host. The following command will create a local proxy for your machine to use on port 8080.

bash
hackpro:~# ssh -q2nCTN -D 8080 user@hostname

The only caveat to this setup is that you will need key authentication setup, it will not work with standard password authentication. The following is a list of the options used..

  • -q = Quiet
  • -2 = SSHv2
  • -n = Do not read from stdin (This is why you need to have private key authentication set up!)
  • -C = Compression
  • -T = Disable pseuto-tty allocation
  • -N = Do not execute a remote command or launch a shell. Uses the ssh connection for port forwarding
  • -D = Allocate a socket to listen on the locally. Whenever a connection is made to this port,
    the connection is forwarded over the secure channel. ( Requires root )

The only thing left to configure is your browser. Set it to use localhost:8080 as a SOCKS proxy. Quick, simple, and perfect! As usual, if you have any questions please feel free to leave a comment below.

Topics

Related Posts

Automation & Tools · 3 min read

Netcat – Secret Weapon

2010.04.19

Netcat or nc, is a forgotten tool in too many arsenals these days. It lays dormant waiting at the command line to make connections across the globe for you.

Comments

1 archived comment from Disqus 2010
halil baysal
For a L3 connection through ssh, search for a more detailed explaination of “ssh “-w”” option. this (if run as root and needed modules loaded) creates a tunx interfaces on the client and server. Give both client and server an ip address on the tunx interfaces, ( linux starts with tun0 and osx with tun15)
the 2 machines can communicate now securly over the internet and you can use internal ip addresses for communication but we can go further whole network forwarding over vpn add your routing " route add -net remote_ip/maskbit “other_point_ip”
for example route add -net 192.168.0.0/24 10.0.0.254 and add in your router the ip addresses of the networks to the vpn machines. and oullah, a vpn setup with 4 commands ;) i start it all in a screen session and detach after everything is done and the vpn with be intact ;)
